RUIJIE REYEE - RG-POE-50-60W-MG - 1-Port 2.5G PoE Injector, 56 V, 60 W

RG-POE-50-60W-MG — 1-Port 2.5G PoE Injector, 56 V, 60 W

The RG-POE-50-60W-MG is a one-port PoE injector: one 2500Base-T data input and one PoE output, with a nominal output of 56 V, 60 W. It runs from a 100-240 V AC mains supply.

What the RG-POE-50-60W-MG is for

An injector adds power to a single Ethernet run where the switch or router upstream cannot supply enough PoE. Ruijie list this model as compatible with three Reyee access points: the RG-RAP2260(H), RG-RAP6260(H) and RG-RAP6260(H)-D.

It powers over all four pairs, on pins 1, 2, 4, 5 (positive) and pins 3, 6, 7, 8 (negative), and passes data at 2500Base-T. Ruijie give the output as 52 V +5% DC at 1.08 A against a nominal rating of 56 V, 60 W. Ruijie do not state a PoE standard for it, so use it only with devices Ruijie list as compatible.

Full specification

What you will need

You need a mains outlet (100-240 V AC), a network cable from your switch or router to the injector's data-in port, and a second cable from the PoE output to the access point. Ruijie list the RG-RAP2260(H), RG-RAP6260(H) and RG-RAP6260(H)-D as compatible. Ruijie's page does not list box contents, so check with us before ordering if you need a mains lead.

Buying from Zenith Security Co.

We are a supplier, not an installer. We will go through the RG-POE-50-60W-MG with you before you buy — which access point it will power, the cable run and whether an injector or a PoE switch port suits the site — and depending on your requirements and your area we can recommend a qualified trade installer. We have been operating since 2012 and you can visit our trade counter in Wolverhampton.

Which access points does the RG-POE-50-60W-MG power?

Ruijie list the RG-RAP2260(H), RG-RAP6260(H) and RG-RAP6260(H)-D as compatible. Tell us your access point model and we will check.

What speed does the RG-POE-50-60W-MG pass?

It has one data-in port and one PoE-out port and is listed as 2500Base-T, so it can carry 2.5G Ethernet.

How is the RG-POE-50-60W-MG powered?

From a 100-240 V AC supply at 50/60 Hz. Its nominal output is 56 V, 60 W, and the output voltage is given as 52 V +5% DC at 1.08 A.

Can I use the RG-POE-50-60W-MG with any PoE device?

Ruijie do not state a PoE standard for it, so use it only with the access points Ruijie list as compatible.

How quickly can I get it?

Delivery is within 1–3 working days to England, Scotland and Wales. We do not ship to Northern Ireland.

Can I collect or see one before buying?

Yes. Our trade counter is at Unit 3, Park View Centre, 243 Dudley Road, Wolverhampton WV2 3JU. Call first so we can confirm the item is there for you.

Questions on specification or compatibility: call 01902 902251, see our FAQ and support pages, or contact us. Trade accounts are available — see trade customers. Browse the full Ruijie Reyee range.
