Dahua DH-PFA143 — IP66 IK10 Outdoor CCTV Surveillance Box

The Dahua DH-PFA143 is an IP66 IK10 outdoor CCTV surveillance box with an all-aluminium shell. It is a white wall mounted enclosure, 450 x 365 x 191 mm, built to take the power supply, switch, MNVR and protective devices of an outdoor CCTV installation, with optional fans for heat dissipation and an optional alarm switch for a tamper alarm.

Also listed as PFA143.

Key features

• All-aluminium shell design, IP66 and IK10 rated.
• Takes a power supply, switch, MNVR and protective devices.
• Optional fans for heat dissipation at high temperature.
• Tamper alarm function with an optional alarm switch.
• Load bearing 10 kg at the front, 6 kg at the side and 5 kg inside.
• Aesthetic design and easy installation; Dahua application drawings show wall mount and pole mount.

Technical specification

Package contents (Dahua package list)

• Outdoor surveillance box DH-PFA143 × 1
• M8 × 80 expansion bolt × 4, M8 × 30 screw × 4, M6 × 10 bolt × 8
• M4 × 10 screw × 8, M4 × 14 screw × 4, M4 × 8 screw × 6, M3 × 8 screw × 2
• S3.0, S5.0 and S6.0 wrench × 1 each
• Water joint × 5, sealing plug × 2, sealing ring × 1, assistant handle × 1
• Terminal block × 2, rail block × 3, user manual × 1

Related Dahua accessories

Other Dahua accessories we list: Dahua DH-PFA6400S waterproof power box, Dahua DH-PFA126 junction box.

Common questions

What is the DH-PFA143 for?

Dahua describes it as an outdoor surveillance box that satisfies the installation of a power supply, switch, MNVR and protective devices, in an all-aluminium IP66 and IK10 shell. In other words it is a CCTV box for the equipment of an outdoor CCTV installation.

Can I fit fans or a tamper alarm?

Dahua lists optional fans for heat dissipation at high temperature, and a tamper alarm function with an optional alarm switch. They are optional and are not in the package list.

How is it mounted and how much can it carry?

The specification gives wall mount, and the application drawings show wall mount and pole mount. Load bearing is 10 kg at the front, 6 kg at the side and 5 kg inside.

What temperature range does it work in?

Dahua gives an operating temperature of -40 °C to +60 °C and humidity of up to 90% RH.

What is in the package?

The box, expansion bolts, screws, bolts, three wrenches, water joints, sealing plugs and ring, an assistant handle, terminal and rail blocks and a user manual, as listed above.

Which equipment fits inside?

Dahua points to its Camera Accessories Selection document for applicable cameras. Tell us the model of your Dahua camera and we will confirm compatibility before you order.

Full manufacturer specification: Dahua product page
