UNIVIEW - IPC3534LE-ADZK-DL3 - 4MP HD Smart Dual-light Motorised Varifocal Turret Network Camera, 2.8-12mm

IPC3534LE-ADZK-DL3 — 4MP HD Smart Dual-light Motorised Varifocal Turret Network Camera, 2.8-12mm

The Uniview IPC3534LE-ADZK-DL3 is a 4MP turret network camera with a motorised 2.8 to 12 mm lens.

What the IPC3534LE-ADZK-DL3 is for

The lens gives a horizontal field of view of 95.6° to 30.9°. Uniview's DORI figures are 63 m to 270 m to detect and 6.3 m to 27.0 m to identify. For low light it has dual light, infrared to 40 m and warm light to 40 m. It is rated IP67 and IK10 for outdoor use (working range -30 °C to 60 °C).

Key features

• 4MP maximum resolution, 1/3.0" CMOS sensor, 120 dB WDR
• Motorised lens, 2.8 to 12 mm, F1.6 iris
• Horizontal field of view 95.6° to 30.9°
• Dual light, infrared to 40 m and warm light to 40 m
• Built-in microphone
• IP67 IK10, PoE (802.3af) or 12 V DC, microSD, up to 512 GB

Full specification

What you will need

Supply PoE (IEEE 802.3af) from a PoE switch or an NVR's built-in PoE ports, or 12 V DC; maximum draw is 4.9 W. Use a network cable for the run. For recording, add a compatible NVR with hard drives, or a microSD card (up to 512 GB). Neither is supplied.

Buying from Zenith Security Co.

We are a supplier, not an installer. We will go through the IPC3534LE-ADZK-DL3 with you before you buy — the 2.8 to 12 mm lens, coverage, and how to power and record from it — and depending on your requirements and your area we can recommend a qualified trade installer. We have been operating since 2012 and you can visit our trade counter in Wolverhampton.

What lens does the IPC3534LE-ADZK-DL3 have?

A motorised 2.8 to 12 mm lens, with a horizontal field of view of 95.6° to 30.9°.

How far can the IPC3534LE-ADZK-DL3 see?

Uniview's DORI figures are 63 m to 270 m to detect and 6.3 m to 27.0 m to identify.

Is the IPC3534LE-ADZK-DL3 PoE?

Yes, it takes DC 12 V ±25%, PoE (IEEE 802.3af), with maximum consumption of 4.9 W.

Does the IPC3534LE-ADZK-DL3 have night lighting?

Yes: dual light, infrared to 40 m and warm light to 40 m.
