UNIVIEW - IPC3514LE-ADF28K-WP - 4MP ColorHunter with Wise-ISP Fixed Dome Network Camera, 2.8mm, White

IPC3514LE-ADF28K-WP — 4MP ColorHunter with Wise-ISP Fixed Dome Network Camera, 2.8mm, White

The Uniview IPC3514LE-ADF28K-WP is a white 4MP ColorHunter fixed dome network camera with a 2.8 mm F1.0 lens and a 1/1.8" CMOS sensor. It is rated IP67 and IK10 for outdoor use.

What the IPC3514LE-ADF28K-WP is for

The 2.8 mm lens gives a 110.4° horizontal field of view, suited to entrances, yards and rooms where a wide view matters. Uniview's DORI figures for this lens are 43.4 m to detect, 17.4 m to observe, 8.7 m to recognise and 4.3 m to identify.

ColorHunter with Wise-ISP is aimed at full-colour images around the clock, with a colour minimum illumination of 0.0003 lux (F1.0, AGC on) and 120 dB WDR. Detection covers cross line and intrusion based on human body detection, plus motion, ultra motion, tampering and audio detection.

Key features

• 4MP (2688 × 1520) at up to 25 fps, 1/1.8" CMOS sensor
• Fixed 2.8 mm F1.0 lens, 110.4° horizontal view
• 0.0003 lux colour minimum illumination, 120 dB WDR
• Built-in mic, 9:16 corridor mode
• IP67, IK10, PoE (802.3af) or 12 V DC, max. 2.8 W
• Micro SD up to 256 GB, ONVIF Profile S, G and T

Full specification

What you will need

Power it from a PoE switch or an NVR's PoE port (IEEE 802.3af), or from 12 V DC through the Ø5.5 mm plug. Run network cable to the camera and add an NVR with surveillance hard drives for continuous recording. A microSD card is optional and not included.

Buying from Zenith Security Co.

We are a supplier, not an installer. We will go through the IPC3514LE-ADF28K-WP with you before you buy — lens choice, PoE or 12 V power, recorder compatibility and how the 4MP dome fits your site — and depending on your requirements and your area we can recommend a qualified trade installer. We have been operating since 2012 and you can visit our trade counter in Wolverhampton.

What lens does the IPC3514LE-ADF28K-WP have?

A fixed 2.8 mm F1.0 lens with a 110.4° horizontal, 60.5° vertical and 115.2° diagonal field of view.

Is the IPC3514LE-ADF28K-WP PoE?

Yes. It takes PoE (IEEE 802.3af) or DC 12 V ±25%, with a maximum consumption of 2.8 W.

Is the IPC3514LE-ADF28K-WP suitable for outdoor use?

It is rated IP67 and IK10 and works from -30°C to 60°C.

Is there a black version?

Yes, the same camera is listed in black as IPC3514LE-ADF28K-WP-BLACK. This listing is the white version.

Is this a trade-price product?

Yes. Uniview products are supplied at trade prices to approved trade customers, so the price is shown once you are logged in to a trade account. Call 01902 902251 or see our trade customer page to open an account.

How quickly can I get it?

We ship nationally from our multi-million pound warehouse, with orders leaving daily. Orders placed before 2:30pm are normally dispatched for delivery within 1–2 working days to England, Scotland and Wales. You can also collect in store from our trade counter — call first so we can confirm your order is ready. We do not ship to Northern Ireland.

Can I collect or see one before buying?

Yes. Our trade counter is at Unit 3, Park View Centre, 243 Dudley Road, Wolverhampton WV2 3JU. Call first so we can confirm the item is there for you.

Questions on specification or compatibility: call 01902 902251, see our FAQ and support pages, or contact us. Trade accounts are available — see trade customers. Browse the full Uniview range.
