UNIVIEW - IPC3634SE-ADF28K-WP-I1 - 4MP HD Intelligent ColorHunter Fixed Turret Network Camera, 2.8mm
Product Features
4MP Uniview turret camera with a 2.8 mm lens, warm light to 30 m, IP67 and IK10. Powered by PoE (802.3af) or 12 V DC. Recorder and microSD card are not included.
IPC3634SE-ADF28K-WP-I1 — 4MP HD Intelligent ColorHunter Fixed Turret Network Camera, 2.8mm
The Uniview IPC3634SE-ADF28K-WP-I1 is a 4MP turret camera with a 2.8 mm lens.
What the IPC3634SE-ADF28K-WP-I1 is for
The lens gives a horizontal field of view of 110.4°. Uniview's DORI figures are 43.4 m to detect and 4.3 m to identify. Supplementary lighting: warm light to 30 m. Minimum illumination is Color: 0.0003 Lux (F1.0, AGC ON).
It is rated IP67 (IEC 60529) IK10 (IEC 62262) NEMA 4X with a working range of -40 °C to 60 °C. Smart intrusion prevention covers cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle).
Key features
- 4MP maximum resolution, 1/1.8" CMOS sensor, 130 dB WDR
- Fixed lens, 2.8 mm, F1.0
- Horizontal field of view 110.4°
- Illumination: warm light to 30 m
- Power: DC 12 V±25%, PoE (IEEE 802.3af); Max. 4.5 W
- Edge storage: MicroSD, up to 512 GB
- Protection: IP67 (IEC 60529) IK10 (IEC 62262) NEMA 4X
Full specification
| Camera | |
| Max Resolution | 4 MP |
| Sensor | 1/1.8" CMOS |
| Min. Illumination | Color: 0.0003 Lux (F1.0, AGC ON) |
| Shutter | Auto/Manual, 1 to 1/100000 s |
| Adjustment Angle | Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360° |
| S/N | >56 dB |
| WDR | 130 dB |
| Lens | |
| Focal Length | 2.8 mm |
| Iris Type | Fixed |
| Iris | F1.0 |
| Field of View (H) | 110.4° |
| Field of View (V) | 60.5° |
| Field of View (D) | 115.2° |
| Lens Type | Fixed |
| DORI | |
| DORI Distance (Lens) | 2.8 mm |
| DORI Distance (Detect) | 43.4 m |
| DORI Distance (Observe) | 17.4 m |
| DORI Distance (Recognize) | 8.7 m |
| DORI Distance (Identify) | 4.3 m |
| Illuminator | |
| Supplemental Light | Warm light |
| Illumination Distance (Warm Light) | 30 m |
| Light On/Off Control | Auto/Manual |
| Video | |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 Code Profile | Baseline profile, Main profile, High profile |
| Frame Rate-Main Stream | 4 MP (2688 × 1520), max. 30 fps; 4 MP (2560 × 1440), max. 30 fps; 3 MP (2304 × 1296), max. 30 fps; 1080P (1920 × 1080), max. 30 fps; 720P (1280 × 720), max. 30 fps |
| Frame Rate-Sub Stream | 1080P (1920 × 1080), max. 30 fps; 720P (1280 × 720), max. 30 fps; D1 (720 × 576), max. 30 fps; 640 × 360, max. 30 fps; 2CIF (704 × 288), max. 30 fps; CIF (352 × 288), max. 30 fps |
| Frame Rate-Third Stream | D1 (720 × 576), max. 30 fps; 640 × 360, max. 30 fps; 2CIF (704 × 288), max. 30 fps; CIF (352 × 288), max. 30 fps |
| Video Bit Rate | 128 Kbps to 16 Mbps |
| U-code | Support |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Support |
| Video Stream | Triple streams |
| Image | |
| White Balance | Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2 |
| Digital Noise Reduction | 2D/3D DNR |
| Auto Scene Match (ASM) | Support |
| Flip | Normal, Flip vertical, Flip horizontal, 180°, 90° Clockwise, 90° Anti-clockwise |
| HLC | Support |
| BLC | Support |
| Defog | Digital defog |
| Intelligent | |
| Smart Intrusion Prevention | Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle) |
| People Counting | Support people flow counting and crowd density detection |
| Attribute Collection | SIP with color retrieval |
| Events | |
| Basic Detection | Motion detection, Ultra motion detection, Tampering alarm, Audio detection, Object removed, Object Left Behind |
| General Function | Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication, Alarm input, Alarm output |
| Audio | |
| Audio Compression | G.711U, G.711A, AAC-LC |
| Audio Bitrate | G.711U/G.711A: 64 kbps, AAC-LC: 128 kbps |
| Two-way Audio | Support |
| Suppression | Support |
| Sampling Rate | G.711U/G.711A: 8 kHz, AAC-LC: 8 kHz, 16 kHz, 48 kHz |
| Storage | |
| Edge Storage | MicroSD, up to 512 GB |
| Network Storage | ANR, NAS (NFS) |
| Network | |
| Security | Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF |
| Protocols | IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, SSL/TLS, SSH |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T, Profile M), API, SDK |
| User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
| Client | EZStation, APP |
| Interface | |
| Audio I/O | 1 Input: impedance 35 kΩ, amplitude 2 V [p-p], 1 Output: impedance 600 Ω, amplitude 2 V [p-p] |
| Alarm I/O | 1/1 |
| Built-in Mic | Support |
| Network | 1 × RJ45 10 M/100 M Base-TX Ethernet |
| Certification | |
| EMC | CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 50130) FCC (FCC 47 CFR part15 B) |
| Safety | CE-LVD (EN 62368-1) CB (IEC 62368-1) UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1) |
| Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU) |
| Protection | IP67 (IEC 60529) IK10 (IEC 62262) NEMA 4X |
| General | |
| Power | DC 12 V±25%, PoE (IEEE 802.3af) |
| Power Consumption | Max. 4.5 W |
| Power Interface | Ø5.5 mm coaxial power plug |
| Dimensions | Ø129 mm × 110 mm (Ø × H) |
| Weight | 0.67 kg |
| Material | Metal |
| Working Environment | -40 °C to 60 °C, Humidity: ≤ 95% RH (non-condensing) |
| Storage Environment | -40 °C to 60 °C, Humidity: ≤ 95% RH (non-condensing) |
| Surge Protection | 4 KV |
| Reset Button | Support |
| Built-in DC12V Output | Support |
What you will need
Power the camera from a PoE switch or NVR PoE port (IEEE 802.3af), or from a 12 V DC supply; maximum consumption is 4.5 W. Run it on suitable network cable. For recording, use a compatible NVR fitted with hard drives, or a microSD card in the camera (up to 512 GB). None of these are supplied.
Buying from Zenith Security Co.
We are a supplier, not an installer. We will go through the IPC3634SE-ADF28K-WP-I1 with you before you buy — the lens and coverage, how the camera will be powered, and which NVR or PoE switch it connects to — and depending on your requirements and your area we can recommend a qualified trade installer. We have been operating since 2012 and you can visit our trade counter in Wolverhampton.
What lens does the IPC3634SE-ADF28K-WP-I1 have?
A 2.8 mm fixed lens at F1.0, with a horizontal field of view of 110.4°.
How is the IPC3634SE-ADF28K-WP-I1 powered?
Uniview lists DC 12 V±25%, PoE (IEEE 802.3af), with max. 4.5 W consumption.
Does the IPC3634SE-ADF28K-WP-I1 work at night?
Yes. It has warm light to 30 m, and colour minimum illumination is 0.0003 lux at F1.0.
Is the IPC3634SE-ADF28K-WP-I1 suitable for outdoor use?
It is rated IP67, IK10 and NEMA 4X and works from -40 °C to 60 °C.
Is this a trade-price product?
Yes. Uniview products are supplied at trade prices to approved trade customers, so the price is shown once you are logged in to a trade account. Call 01902 902251 or see our trade customer page to open an account.
How quickly can I get it?
We ship nationally from our multi-million pound warehouse, with orders leaving daily. Orders placed before 2:30pm are normally dispatched for delivery within 1–2 working days to England, Scotland and Wales. You can also collect in store from our trade counter — call first so we can confirm your order is ready. We do not ship to Northern Ireland.
Can I collect or see one before buying?
Yes. Our trade counter is at Unit 3, Park View Centre, 243 Dudley Road, Wolverhampton WV2 3JU. Call first so we can confirm the item is there for you.
Questions on specification or compatibility: call 01902 902251, see our FAQ and support pages, or contact us. Trade accounts are available — see trade customers. Browse the full Uniview range.
| Product Code | IPC3634SE-ADF28K-WP-I1 |
|---|---|
| Manufacturer | Uniview |
| Colour | White |
| Max Resolution | 4MP |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Min. Illumination | Colour: 0.0003 Lux (F1.0, AGC ON) |
| WDR | 130 dB |
| Lens Type | Fixed |
| Protection Level, Ingress Protection | IP67 |
| Operating Temperature | -40 °C to 60 °C |
| Local Storage | MicroSD, up to 512 GB |
| Indoor/Outdoor | Indoor / Outdoor |
