UNIVIEW - UNV-VD0116-UH-EU - 4K HDMI Splitter, 1 In 16 Out

UNV-VD0116-UH-EU — 4K HDMI Splitter, 1 In 16 Out

The Uniview VD0116-UH is an HDMI splitter that takes one HDMI source and sends the same picture to sixteen HDMI displays, at up to 4K at 60 Hz.

What the UNV-VD0116-UH-EU is for

It is used to show one recorder, PC or media player output on many screens at once, such as a control room video wall of monitors or several displays across a site. It supports HDMI 2.0b, HDCP 2.2 and 18 Gbps bandwidth, with HDR formats including HDR10, HDR10+, HLG and Dolby Vision.

An EDID dial switch sets how the splitter reports display capability to the source. It has a metal case, a power switch, input and per-output status LEDs and a service port for firmware upgrades.

Key features

• 1 × HDMI input, 16 × HDMI outputs
• Up to 4K2K at 50/60 Hz, 4:4:4
• HDMI 2.0b, HDCP 2.2, 18 Gbps video bandwidth
• HDR, HDR10, HDR10+, HLG and Dolby Vision
• EDID dial switch and firmware service port
• Metal case, 300 × 100 × 28 mm, 12 V 2.5 A supply

Full specification

What you will need

An HDMI source, such as an NVR or PC, up to sixteen HDMI displays, and HDMI cables rated for the resolution you are running. A mains outlet is needed for the 12 V power supply.

Buying from Zenith Security Co.

We are a supplier, not an installer. We will go through the UNV-VD0116-UH-EU with you before you buy — source resolution, number of screens and EDID settings — and depending on your requirements and your area we can recommend a qualified trade installer. We have been operating since 2012 and you can visit our trade counter in Wolverhampton.

How many screens can the VD0116-UH drive?

Sixteen. It has one HDMI input and sixteen HDMI outputs, all showing the same picture.

Does it support 4K at 60 Hz?

Yes, up to 4K2K at 50/60 Hz, with 18 Gbps bandwidth and HDMI 2.0b.

Does it support HDCP and HDR?

It supports HDCP 2.2, and HDR, HDR10, HDR10+, HLG and Dolby Vision.

How is it powered?

From an AC 100 to 240 V adaptor with a 12 V 2.5 A output; maximum consumption is 12 W.

Is this a trade-price product?

Yes. Uniview products are supplied at trade prices to approved trade customers, so the price is shown once you are logged in to a trade account. Call 01902 902251 or see our trade customer page to open an account.

How quickly can I get it?

We ship nationally from our multi-million pound warehouse, with orders leaving daily. Orders placed before 2:30pm are normally dispatched for delivery within 1–2 working days to England, Scotland and Wales. You can also collect in store from our trade counter — call first so we can confirm your order is ready. We do not ship to Northern Ireland.

Can I collect or see one before buying?

Yes. Our trade counter is at Unit 3, Park View Centre, 243 Dudley Road, Wolverhampton WV2 3JU. Call first so we can confirm the item is there for you.

Questions on specification or compatibility: call 01902 902251, see our FAQ and support pages, or contact us. Trade accounts are available — see trade customers. Browse the full Uniview range.
