Hikvision Video Intercom: 2-Wire HD, 4-Wire 720p and All-in-One Indoor Stations

Hikvision video intercom now covers every type of building: 2-wire HD systems that reuse the existing cable in apartment blocks, 4-wire 720p analogue kits for houses, and an all-in-one indoor station that controls doors, alarms and cameras from one touch screen. This guide brings together Hikvision's intercom announcements from 2021 and 2023 and explains which system suits which job.

2-wire HD intercom (December 2023): upgrade without rewiring

Replacing an old door entry system in a block of flats usually stops at one question: do we have to rewire the building? Hikvision's 2-wire HD system is designed to reuse the existing two-core cable and work with the wiring layouts common in apartment buildings, from single floors to multi-building sites.

• More bandwidth over old cable, giving clearer pictures and control signals comparable to IP.
• 2MP door station video with WDR for faces in bright backlight.
• 7-inch touch-screen indoor stations with a tablet-style feel.
• Answer and unlock from anywhere with the Hik-Connect app.
• Plug-and-play set-up: connect a phone to the device's Wi-Fi hotspot and configure it in a mobile browser, with no PC software needed.
• Connection status can be checked from a mobile browser for quick fault-finding.

4-wire 720p analogue intercom (December 2023): simple HD for houses

For villas and houses, Hikvision launched a 4-wire HD analogue system using its HD-TVI technology:

• 720p HD video, sharper than traditional analogue (CVBS) intercoms.
• Plug and play: connect the wires and it works. Adjust ringtone, unlock time, brightness and volume with buttons on the indoor station.
• Up to 100 metres of cable (AWG16), with up to 2 door stations and 3 indoor stations in one system.
• Connect analogue cameras directly to the indoor station to view the garage or driveway.

All-in-one indoor station (July 2021): one screen for the whole building

The All-in-one Indoor Station is a wall-mounted tablet that acts as a control centre for Hikvision devices through the built-in Hik-Connect app:

• Unlock doors, answer the intercom, watch cameras and NVRs, and arm or disarm the alarm, all with a tap.
• Check device, network and battery status, and room temperature.
• Installers can create linkage rules, for example linking the alarm with CCTV for video verification.

Which intercom should you choose?

• Apartment block with existing 2-core cable: 2-wire HD.
• House or small building, simple and low cost: 4-wire analogue HD.
• New build, offices or a system that needs integration: IP intercom over network cable.

Our Hikvision video intercom buying guide explains the IP, 2-wire HD and 2-wire IP families in detail.

Hikvision intercom products we stock

• 2-wire HD indoor stations: DS-KH7300EY-TE2 and the Wi-Fi DS-KH7300EY-WTE2, also in white.
• 2-wire HD distributors: DS-KAD7060EY and the cascade DS-KAD7060EY-S for larger buildings.
• 2-wire IP: DS-KH6320Y-WTE2 indoor station.
• IP indoor station: DS-KH6320-TE1.

Browse the full intercom range. Mixing generations can cause compatibility problems, so send us your parts list and we'll check it.

Our take

The 2-wire HD system is the big one for property managers. Being able to upgrade a block's door entry to HD video and app unlocking without rewiring every flat changes the cost of the job completely. For houses, the 4-wire kit keeps things simple, and the all-in-one station suits anyone who wants alarm, doors and cameras on one screen by the front door.

Planning an intercom upgrade? Call 01902 902251. As an authorised Hikvision partner, we ship nationally to England, Scotland and Wales.

Quick questions

Can I reuse my old intercom cable?
Hikvision's 2-wire HD system is designed to reuse existing two-core wiring in many apartment buildings. Check the cable condition and topology first.

Can I answer the door on my phone?
Yes. Hikvision 2-wire HD and IP intercoms work with the Hik-Connect app to answer calls and unlock doors remotely.

How far can the 4-wire system run?
Hikvision quotes up to 100 metres of AWG16 cable.

What is the All-in-one Indoor Station?
A wall-mounted touch screen that manages Hikvision intercom, access control, alarms and cameras through Hik-Connect.

Sources: Hikvision UK newsroom, 6 July 2021, 5 December 2023 and 13 December 2023.
